Open-Q™ 820 (APQ8096) / 820Pro (APQ8096SG) µSOM Development Kit User Guide Version 1.4
Domain
GPS Antenna
GPS External Antenna
via SMA Connector
Coin Cell
Holder(Optional)
LED
LCD Display and Touch
connector
Gen10 connector
VIP Extension
connector
Ethernet AVB connector
PCI Express Slot
Description
PCB Antenna
SMA connector for
external GPS antenna
Coin Cell battery(Optional
via stuffing)
3xLED
100 pin for LCD signals
via b2b connector to
display adapter board
Connector for
Qualcomm's internal
sensor boards
Connector for interfacing
with Qualcomm® legacy
automotive VIP boards
Connector for interfacing
with Ethernet AVB
standard
PCI Express for external
peripheral connectivity
Copyright Intrinsyc Technologies Corporation
Specification
GPS :
1574.42 MHz – 1576.42
MHz
GLONASS :
1587 MHz – 1606 MHz
Supports active antenna
Coin cell battery for PMIC
RTC
Red : PMIC Driven
Green: PMIC Driven
Blue: PMIC Driven
4-lane MIPI DSI0 , DSI1
I2C/SPI/GPIO
Backlight
MIPI Alliance Specification
v1.01
MIPI D-PHY Specification
v0.65,v0.81, v0.90, v1.01
60 pin connector sensor
Gen 10
60 pin connector
60 pin connector
PCIe1 v2.1
Supports half card only
Supports 10W card via
power supply
20
Usage
Antenna to µSOM GPS
module
External GPS antenna
RTC
Blue : General Purpose
Red : Charging
Green : Charging
complete
Can work as one dual
DSI or both independent
display
To interface with
Qualcomm's internal
sensor boards (for
Intrinsyc internal use
only – not supported)
Can be used for other
purposes.
To connect to
Qualcomm® legacy
automotive VIP boards
(for Intrinsyc internal
use only – not
supported) Can be
used for other
purposes.
To connect to
automotive peripherals
via Ethernet AVB
standard (for Intrinsyc
internal use only – not
supported) Can be
used for other
purposes.
To connect an Ethernet
PCIe card board to
support Ethernet.
