Navigation in Down Imaging Views

To mark waypoints and start navigation, the control head must have a GPS Fix from a connected or internal GPS receiver. See
Getting Started for more information.
Mark a Waypoint
You can mark a waypoint at the boat position or the cursor position. Waypoints are saved to the Waypoint Management dialog box
(see Manage your Navigation Data).
Mark a Waypoint at the Boat Position
1. Press the MARK key.
Mark a Waypoint at the Cursor Position
1. Use the Cursor Control key to move the cursor to a position on the view.
2. Press the MARK key twice.
cursor depth
cursor
digital
readouts
cursor
Marking a Waypoint at the Cursor Position
depth below cursor distance to cursor position
Move the Cursor
89
bearing to cursor position
Press Twice to
Mark a Waypoint
Down Imaging Sonar
