Review Sonar History

Press any arrow on the Cursor Control key, and the sonar history will freeze and the cursor will display on-screen. If you move the
cursor over a sonar return, digital readouts for the cursor position are displayed on the view. The RTS Window continues to update
at the fastest rate possible for depth conditions (see Customize the Sonar View).
Freeze the Sonar History
1. Press any arrow on the Cursor Control key.
2. Move the cursor over a sonar return.
NOTE: To mark a waypoint or start navigation to the cursor position, see Navigation in Sonar Views.
cursor depth
cursor
digital
readouts
cursor
Sonar (2D)
Reviewing the Depth of the Cursor Position
depth below cursor distance to cursor position
Move the Cursor
68
bearing to cursor position
RTS Window
