Navigation in Side Imaging Views

To mark waypoints and start navigation, the control head must have a GPS Fix from a connected or internal GPS receiver. See
Getting Started for more information.
Turn on/off SI Navigation
SI Navigation controls how the boat icon is displayed in Side Imaging Views. See Navigate to a Position for more information.
If SI Navigation is turned on, an arrow icon indicates the direction the boat needs to turn to reach the next waypoint during
navigation.
If SI Navigation is turned off, the boat icon will not change during navigation although you can still mark waypoints and start
navigation from a Side Imaging View.
1. Main Menu: Press the MENU key twice. Select the Nav tab.
2. Select SI Navigation.
3. Select On or Off.
Mark a Waypoint
You can mark a waypoint at the boat position or the cursor position. Waypoints are saved to the Waypoint Management dialog box
(see Manage your Navigation Data).
Mark a Waypoint at the Boat Position
1. Press the MARK key.
Mark a Waypoint at the Cursor Position
1. Use the Cursor Control key to move the cursor to a position on the view.
2. Press the MARK key twice.
Navigate to a Position
Use the instructions in this section to start navigation to a position in the view. See Navigation Overview for more information
about these features.
Navigate to the Cursor Position
1. Use the Cursor Control key to move the cursor to a position on the view.
2. Press the GOTO key twice.
When you press the GOTO key, a waypoint will be marked at the cursor position.
Navigate to a Saved Position
If you press the GOTO key, you can choose to start navigation from a list of saved waypoints and routes.
1. Press the GOTO key.
2. Select Nav Data. Press the RIGHT Cursor key.
3. Use the Cursor Control key to select a saved waypoint or route.
4. Press the RIGHT Cursor key to start navigation.
