Change the Flasher Window Style
The Flasher Window displays the depth and intensity of the sonar returns. You can change the display style for the sonar returns
using the instructions below. You can also change the sonar colors used for sonar returns. For details, see Change the Sonar Colors
Palette.
1. Flasher X-Press Menu: With the Flasher View displayed on-screen, press the MENU key once.
2. Select Flasher Style.
3. Select the type of Flasher Style to display.
Color (Full)
Color (A-Scope)
The size of the sonar returns correspond with the intensity of the sonar returns from the transducer beam(s).
Sonar returns are displayed in color, and they fill the width of the Flasher Window.
Sonar returns are displayed in color. The size of the displayed lines correspond with the intensity
of the sonar returns from the transducer beam(s).
Flasher Style Set to Color (A-Scope)
