Humminbird HELIX Series Operation Manual page 66

Change the Sonar Colors Palette
The Sonar X-Press Menu allows you to quickly change the display palette while you fish. See Customize the Sonar View: Change
the View Colors for more information.
1. Sonar X-Press Menu: With a Sonar View displayed on-screen, press the MENU key once.
2. Select Sonar Colors.
3. Select a palette.
NOTE: To display or hide the Color Bar, see Customize the Sonar View.
Switch Frequencies
If the transducer includes more than one downbeam frequency, use the CHECK/INFO key to quickly change the frequency used in
the 2D Sonar View. For more information see Sonar Overview and Set up Sonar.
1. With a Sonar View displayed on-screen, press the CHECK/INFO key.
frequency
label
Sonar (2D)
Using the CHECK key to Switch Frequencies
Switch Frequencies
66
