Humminbird HELIX Series Operation Manual page 51

Display a Sonar Combo View
1. Press and hold the VIEW key.
2. To open a Sonar Combo View, select Sonar.
To open a Chart Combo View (Sonar and Chart together), select Chart.
3. Select a view to display on-screen.
Sonar > Down/Sonar Combo View
For more information, see the Down Imaging section.
NOTE: The available views are determined by your control head model and the installed transducer. For a complete list of the
views available on your control head, press the MENU key twice, and select the Views tab. See each related section of the manual
(Views, Down Imaging, Side Imaging, Navigation Overview, etc.) for more information.
Sonar > Side/Sonar Combo View
For more information, see the Side Imaging section.
51
Chart > Chart/Sonar Combo View
(Map Source: Contour XD)
For more information, see Navigation Overview.
Sonar (2D)
