HELIX 7 Control Head Measurements
HELIX 7 Gimbal Mount
10.54 in (267.72 mm)
5.44 in
5.80 in
(138.18 mm)
(147.32 mm)
2.97 in (75.44 mm)
3.60 in (91.44 mm)
262
