Add Settings with Chart Options
You can also add adjustments to your custom map using the HB Chart menu. For example, if Humminbird is set as the map source,
you can add Depth Colors, Shallow Water, etc. to your AutoChart Live map. See Display Humminbird LakeMaster Contour Lines and
Depth Ranges or Display Humminbird LakeMaster Contour Lines and Depth Ranges.
If Navionics is set as the map source, you can display Contours and Shading on your AutoChart Live map. See Customize the Chart
View for more information.
Change the Water Level Offset
When you start your mapping for the day, it is important to note if the water level is higher or lower than usual. See Prepare the
Control Head for Mapping for more information.
1. Main Menu: Press the MENU key twice. Select the HB Chart tab.
2. Select Water Level Offset.
3. Use the RIGHT or LEFT Cursor keys to adjust the setting.
If the water level is higher than normal, set a positive amount.
If the water level is lower than normal, set a negative amount.
If the water level has not changed (normal), turn off Water Level Offset.
AutoChart Live
Adding Shallow Water Settings to the Map
(Map Source: Humminbird LakeMaster)
