HELIX 5 Control Head Measurements
4.28 in
(108.71 mm)
HELIX 5 Gimbal Mount
7.55 in (191.77 mm)
2.90 in (73.66 mm)
3.30 in (83.82 mm)
243
VIEW
4.64 in
MENU
(117.86 mm)
MARK
EXIT
GOTO
