Open the AutoChart Menu
You will use the AutoChart menu for all settings. Some of the menu options in this section may be displayed in other parts of the
menu system so that you can access them quickly. No matter where you make the change, the control head will update the setting
across the system.
1. Chart X-Press Menu: With a Chart View displayed on-screen, press the MENU key once.
2. Select AutoChart. Press the RIGHT Cursor key.

Display the AutoChart Live Map

You can make changes to the AutoChart Live map during recording or after you've saved your map. You can also view bottom
hardness or vegetation data, and you can customize how the data is displayed.
Show/Hide the AutoChart Live Map
The custom map can be displayed or hidden while you are recording or after the map is saved. You can also adjust the transparency.
Show the AutoChart Live Map
1. From the AutoChart menu, select AutoChart.
2. Select Visible (LakeMaster) or press the CHECK/INFO key or the RIGHT Cursor key to add a check mark (CoastMaster).
Hide the AutoChart Live Map
1. From the AutoChart menu, select AutoChart.
2. Select Hidden (LakeMaster) or press the CHECK/INFO key or the RIGHT Cursor key to remove the check mark (CoastMaster).
AutoChart Live
Chart View with AutoChart Live Map Displayed
206
AutoChart Color Bar
set to AutoChart
