Zoom In/Out in Flasher View

The Zoom feature displays a 2x magnified view of the area you choose on the Flasher View.
NOTE: Ice Fishing Mode must be turned on to enable this feature (see Ice Fishing Overview: Turn on Ice Fishing Mode).
ZOOM In/Out using the ZOOM Keys (GPS models only)
1. Activate: Press the +ZOOM key.
2. Adjust the Zoom Range: Press the RIGHT or LEFT Cursor keys to move the white zoom lines on the flasher dial.
3. Close Zoom: Press -ZOOM key.
ZOOM In/Out using the Flasher X-Press Menu
If your control head model does not include ZOOM keys, you will use the Zoom Level menu.
1. Flasher X-Press Menu: With the Flasher View displayed on-screen, press the MENU key once.
2. Select Zoom Level.
3. Select 2X.
4. Adjust the Zoom Range: Press the RIGHT or LEFT Cursor keys to move the white zoom lines on the flasher dial.
5. Close Zoom: Press the MENU key. Select Zoom Level > 1X.
