TMnDL Register
Bit 7
�a�e D7
R/W R
POR 0
Bit 7~0 TM1DL: TM1 Counter Low Byte Register bit 7~bit 0
TM1 10-bit Counter bit 7~bit 0
TMnDH Register
Bit 7
�a�e —
R/W —
POR —
Bit 7~2 Unimplemented, read as "0"
Bit 1~0 TM1DH: TM1 Counter High Byte Register bit 1~bit 0
TM1 10-bit Counter bit 9~bit 8
TMnAL Register
Bit 7
�a�e D7
R/W R/W
POR 0
Bit 7~0 TM1AL: TM1 CCRA Low Byte Register bit 7~bit 0
TM1 10-bit CCRA bit 7~bit 0
TMnAH Register
Bit 7
�a�e —
R/W —
POR —
Bit 7~2 Unimplemented, read as "0"
Bit 1~0 TM1AH: TM1 CCRA High Byte Register bit 1~bit 0
TM1 10-bit CCRA bit 9~bit 8
