INTC2 Register
Bit 7
�a�e MF�F
R/W R/W
POR 0
MF3F: Multi-function Interrupt 3 Request Flag
Bit 7
0: No request
1: Interrupt request
TB1F: Time Base 1 Interrupt Request Flag
Bit 6
0: No request
1: Interrupt request
TB0F: Time Base 0 Interrupt Request Flag
Bit 5
0: No request
1: Interrupt request
MF2F: Multi-function Interrupt 2 Request Flag
Bit 4
0: No request
1: Interrupt request
MF3E: Multi-function Interrupt 3 Control
Bit 3
0: Disable
1: Enable
TB1E: Time Base 1 Interrupt Control
Bit 2
0: Disable
1: Enable
TB0E: Time Base 0 Interrupt Control
Bit 1
0: Disable
1: Enable
MF2E: Multi-function Interrupt 2 Control
Bit 0
0: Disable
1: Enable
MFI0 Register
Bit 7
�a�e —
R/W —
POR —
Bit 7~6 Unimplemented, read as "0"
Bit 5 T0AF: TM0 Comparator A match interrupt request flag
0: no request
1: interrupt request
Bit 4 T0PF: TM0 Comparator P match interrupt request flag
0: no request
1: interrupt request
Bit 3~2 Unimplemented, read as "0"
Bit 1 T0AE: TM0 Comparator A match interrupt control
0: disable
1: enable
Bit 0 T0PE: TM0 Comparator P match interrupt control
0: disable
1: enable
Rev. 1.40
HT66F20-1/HT66F30-1/HT68F20-1/HT68F30-1
6 5 4
TB1F TB0F MF�F
R/W R/W R/W
0 0 0
6 5 4
— T0AF T0PF
— R/W R/W
— 0 0
1��
Flash MCU with EEPROM
3 2 1
MF�E TB1E TB0E
R/W R/W R/W
0 0 0
3 2 1
— — T0AE
— — R/W
— — 0
�ove��e� ��� �01�
0
MF�E
R/W
0
0
T0PE
R/W
0
