Holtek HT66F20-1 Manual page 70

Reset
Register
(Power-on)
PRM0 - - - - - 0 0 0
TM1C0 0 0 0 0 0 0 0 0
TM1C1 0 0 0 0 0 0 0 0
TM1C� 0 0 0 0 0 0 0 0
TM1DL 0 0 0 0 0 0 0 0
TM1DH - - - - - - 0 0
TM1AL 0 0 0 0 0 0 0 0
TM1AH - - - - - - 0 0
TM1BL 0 0 0 0 0 0 0 0
TM1BH - - - - - - 0 0
SCOMC 0 0 0 0 0 0 0 0
Note: " - " stands for not implement
" u " stands for unchanged
" x " stands for unknown
Rev. 1.40
HT66F20-1/HT66F30-1/HT68F20-1/HT68F30-1
Flash MCU with EEPROM
RES or LVR WDT Time-out
Reset (Normal Operation)
- - - - - 0 0 0 - - - - - 0 0 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
- - - - - - 0 0 - - - - - - 0 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
- - - - - - 0 0 - - - - - - 0 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
- - - - - - 0 0 - - - - - - 0 0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
70
WDT Time-out
(IDLE)
- - - - - u u u
u u u u u u u u
u u u u u u u u
u u u u u u u u
u u u u u u u u
- - - - - - u u
u u u u u u u u
- - - - - - u u
u u u u u u u u
- - - - - - u u
u u u u u u u u
