HT66F20-1/HT66F30-1/HT68F20-1/HT68F30-1
Flash MCU with EEPROM
MFI1 Register
• HT66F20-1/HT68F20-1
Bit 7
�a�e —
R/W —
POR —
Bit 7~6 Unimplemented, read as "0"
Bit 5 T1AF: TM1 Comparator A match interrupt request flag
0: no request
1: interrupt request
Bit 4 T1PF: TM1 Comparator P match interrupt request flag
0: no request
1: interrupt request
Bit 3~2 Unimplemented, read as "0"
Bit 1 T1AE: TM1 Comparator A match interrupt control
0: disable
1: enable
Bit 0 T1PE: TM1 Comparator P match interrupt control
0: disable
1: enable
• HT66F30-1/HT68F30-1
Bit 7
�a�e —
R/W —
POR —
Bit 7 Unimplemented, read as "0"
Bit 6 T1BF: TM1 Comparator B match interrupt request flag
0: no request
1: interrupt request
Bit 5 T1AF: TM1 Comparator A match interrupt request flag
0: no request
1: interrupt request
Bit 4 T1PF: TM1 Comparator P match interrupt request flag
0: no request
1: interrupt request
Bit 3 Unimplemented, read as "0"
Bit 2 T1BE: TM1 Comparator B match interrupt control
0: disable
1: enable
Bit 1 T1AE: TM1 Comparator A match interrupt control
0: disable
1: enable
Bit 0 T1PE: TM1 Comparator P match interrupt control
0: disable
1: enable
Rev. 1.40
6 5 4
— T1AF T1PF
— R/W R/W
— 0 0
6 5 4
T1BF T1AF T1PF
R/W R/W R/W
0 0 0
1�7
3 2 1
— — T1AE
— — R/W
— — 0
3 2 1
— T1BE T1AE
— R/W R/W
— 0 0
�ove��e� ��� �01�
0
T1PE
R/W
0
0
T1PE
R/W
0
