CAMERA CART
4.3.2

Operating Position

How to Put Camera Cart into Operating Position
Steps
1.
2.
3.
4.
5.
6.
7.
Positioning Considerations
In case of interference with other devices caused by the IR light emitted by the camera, reposition
the camera and/or affected device until there is no longer interference.
Reflections of IR light, e.g., from drapes or shiny surfaces, may interfere with the camera's
ability to correctly track instruments. The same may be true of the camera's IR light, which
can interfere with other devices, e.g., pulse oximeter, remote control systems or IR
sensitive microscopes.
Safe Positioning
Lock all four wheel brakes when Camera Cart is in operating position.
Do not place Camera Cart or any of its parts over the patient.
System User Guide Rev. 1.0 Curve Dual Navigation Station Ver. 1.2
Ensure that Camera Cart is in transport position (see page 113).
Using the transport handle, move Camera Cart to desired location.
Lock all four wheel brakes (see page 107).
Remove camera protection cover.
Grip camera handle and move camera arm to desired position
NOTE: The gas spring of the camera joint keeps the camera in desired position.
Plug camera cable into Monitor Cart.
Attach Sterile Camera Handle Sleeve to camera handle.
