Sterile Use
How to Attach/Remove Sterile Camera Handle Drape
Options
To attach Sterile Camera Handle Drape ②, slide it over camera handle ① until it snaps into
place.
To remove Sterile Camera Handle Drape ② from the camera handle ①, pull the drape off.
NOTE: Avoid coming in contact with the camera cable ③ when adjusting the camera sterilely.
Verify that Sterile Camera Handle Drape has snapped properly into place.
100
①
②
Figure 48
System User Guide Rev. 1.0 Curve Dual Navigation Station Ver. 1.2
③
