TRANSPORT
7.2.3

Docking and Undocking Procedure

How to Dock
Steps
1.
2.
3.
4.
Do not try attempt to dock anything other than the Camera Cart to the Monitor Cart.
Final Docked Position
System User Guide Rev. 1.0 Curve Dual Navigation Station Ver. 1.2
Bring Camera Cart and Monitor Cart into the respective parking positions.
Ensure that the brakes of Monitor Cart are engaged.
Ensure that locking mechanism is open.
If locking mechanism has been unintentionally snapped in, open it by pressing release
pedal downwards (see page 116).
Push Camera Cart into Monitor Cart so that the front axle of Camera Cart encloses the
front axle of Monitor Cart until locking mechanism audibly snaps into place.
NOTE: It is recommended to always move the Camera Cart into the Monitor Cart and
not the other way around.
Figure 57
