System Setup

2.2 System Setup

Curve Optical Tracking

General Information
The Curve system is an optical-tracking, touchscreen-operated planning and navigation system
designed for pre- and intraoperative use.
• Monitor Cart and Camera Cart are delivered pre-installed and ready for use.
• All system components are suitable for continuous use during surgical procedures.
• Only use system components indoors, in an operating room.
How to Safely Position the System
Steps
1.
2.
3.
4.
5.
6.
7.
8.
Ensure that the system is set up so it is not possible for the patient to touch or come in
contact with the equipment.
Ensure that the system is set up in a way that the mains power plug on the Monitor Cart is
easily accessible. In case of malfunction, you must be able to easily unplug the mains
power cable.
Sterile Field
The Curve system is unsterile.
Do not allow the camera, monitors or any other part of the Curve system to enter the sterile
field.
Interferences
If camera's infrared light interferes with other devices, reposition these devices and/or the camera
so that the interference is resolved.
The camera's infrared light may interfere with other IR-based OR equipment, such as
remote controls, pulse oximeters or IR-sensitive microscopes.
22
Remove protection covers from display and camera before entering the OR. Page 108
Move equipment into the OR
Angle the system so that:
• The Curve logo on the Monitor Cart points toward the patient
• User and connection panels and the Camera Cart connector point away
from the patient
NOTE: Do not position the camera, monitors or any other part of the Curve
system directly over the patient.
Lock all brakes on the Monitor Cart and Camera Cart.
Move monitors into desired position.
Lock all locks on the monitor arms.
Move camera into desired position.
Connect all cables at the connection panel.
System User Guide Rev. 1.0 Curve Dual Navigation Station Ver. 1.2
See
Page 119
Page 25
Page 105
Page 44
Page 46
Page 70
Page 48
