Figure 33 — Bypass Aux Contacts
B
AMPS HP2 3-30
5.6 DC Connections
5
• Access to connection points is provided through the opening in the top and back of the system rack.
• DC wires enter the cabinet through the top of the cabinet.
A
• A low voltage disconnect should be provided with the battery system.
5
5.6.1 DC Battery Cabling
DC battery cable terminations are designed for two-hole spade lugs (3/8" diameter on 1" centers) crimped to the
5
cabling, then attached to the bus bars. See Figure 32.
Torque specifications for DC wiring (3/8" bolts that attach the DC lugs at the back of the DC distribution box) are
190 – 240 inch/lbs (21.5 – 27.1 N-m).
54
4
4 3
5
DC2 -
Figure 35 — DC Connections, DC1 and DC2
4
DO NOT SCALE DRAWING
Figure 34 — Bypass Aux Contacts
3
UNLESS OTHERWISE SPECIFIED
DIM ARE IN INCHES
DO NOT SCALE DRAWING
X.X 0.040
X.XX 0.020
X.XXX 0.010
ANGULAR: 1
INTERPRET DIM AND TOL PER
ASME Y14.5-1994
THIRD ANGLE PROJECTION
2
4
REMOVE DC SHORTING BAR
FOR SPLIT BUS USE
DC1 -
3
AMPS HP2 1-10 and 2-20
