Alpha Technologies AMPS HP2 Power System Installation & Operation Manual page 26

4.2.5 Unpacking Instructions
WARNING!
The AMPS HP2 rack weighs 320 kg / 700 lb. Care must be taken to ensure that it does
not topple over.
1. Loosen the four screws securing the upper side panel, and the four screws securing the lower side panel.
2. Lift off the upper side panel, then lift off the lower side panel.
3. Remove the four bolts securing the AMPS HP2 to the wooden pallet.
24
Use 3/4" wrench or
socket to remove
0260080-J0 Rev D
