Mid Mount 20 KVA with 19 - 23" Adapter Plates
Mid Mount 10 KVA with 19 - 23" Adapter Plates
0260080-J0 Rev D
MID MOUNT 20 KVA WITH ADAPTER PLATES
MID MOUNT 10 KVA WITH ADAPTER PLATES
19"- 23"
19"- 23"
7X 1/2" TRS SCREWS PER SIDE
2X 20 KVA MID MOUNT BRACKET 5903487-002
5X 1/2" TRS SCREWS PER SIDE
2X10 KVA MID MOUNT BRACKET 5903487-001
7X 1/2" TRS SCREWS
FOR RACK INSTALL
PER SIDE
2X 9 RU ADAPTER PLATE
5901456-009
2X 2 RU ADAPTER PLATE
5901456-002
5X 1/2" TRS SCREWS
FOR RACK INSTALL
PER SIDE
2X 9 RU ADAPTER PLATE
5901456-009
