3. Module Specifications

3.1 Specifications for 48-120 Inverter Module

General specifications:
EMC (immunity):
EMC (emission):
Safety:
Cooling:
MTBF:
Efficiency (typical):
Enhanced Power Conversion:
On Line:
AC Output Power
Nominal:
Resistive Load:
Overload Capacity (short):
Overload Capacity (permanent):
DC Input
Nominal:
Range (Vdc):
Nominal Current (@40 Vdc):
Max input current (5 s):
Voltage Ripple:
AC Input Specifications
Nominal Voltage (AC):
Voltage Range (AC):
Power Factor:
Frequency Range (selectable):
Frequency Tolerance:
AC Output
Nominal (AC)*:
Frequency:
Frequency Accuracy:
Transient Load Recovery Time:
Transfer Performance
Maximum Voltage Interruption:
Total Transient Voltage Duration: 0 s
Environmental
Operating Temperature:
Storage Temperature:
Humidity:
Elevation:
Miscellaneous
Dimensions:
Weight:
0260080-J0 Rev D
EN 61000-4
EN55022 (Class A), FCC 47 VFR Part 15, class A
IEC 60950, UL 1778 Issue 4
Forced Air
240000 hrs
94%
89%
2500 VA
2000 W
150% @ 5 s
110%
48 V
40 to 60 V
56 A
84 A
2 mV
120 Vac
90 to 140 Vac (adjustable)
> 99%
60 Hz
± 3 Hz (adjustable)
120 Vac Accuracy 2%
60 Hz (Same as input frequency in EPC mode)
0�03%
0�4 ms
0 s
-20 to +40°C
-40 to +70°C
Up to 95% non-condensing
<1500M
2 RU H x 102 mm W x 435 mm D
5 kg (11 lb.)
15
