4.7.5 Battery Feed Connections
Battery cable lugs
(3/8" diameter on 1"
centers)
Tie bars
Figure 24 — Single Battery Feed
Tie bars
Figure 25 — Dual Independent Battery Feeds
Figure 26 — Four Independent Battery Feeds (use with no tie bars)
0260080-J0 Rev D
40
