4.7.3 Top Feed Configured Systems (only)
DC+
1
2
3
4
5
6
DC -
Figure 18 — Top Feed System, Single Battery Feed
Cable Tie Bar: For use between
all cable landings (6 total)
0260080-J0 Rev D
34
