5.1 Specifications AMPS HP2: Rack Mount

Model
AC AC Input Voltage
Input
Full Load inverter AC Input
Current (per phase)
AC Input poles & wiring
Wiring
AC inverter input Breaker/
fuse See Note: 2
Recommended
AC Input
Wire size,
90ºC copper
See Note: 1
AC Total AC Output (Max)
AC Output Voltage
Output
AC Output poles & wiring
Wiring
AC Output Current (per
Phase)
Installed Inverter Input &
Output Circuit Breaker
Recommended AC Output
Wire size, 90ºC copper
See Note: 1
AC Input & Output Connection Terminals: Box lugs are rated for both Aluminum and Copper wire, #2/0 to #6 AWG�
Fasten clamping screw to 120 in-lb. (14 N-m).
Note 1 Inverter AC Input & AC Output connections: Calculations based on full load and t, 0.8 derating with 4
Note 2 Consult your local and national electrical codes. AC source must be limited to 5kA Short Circuit Current.
42
AMPS-3-30
120/208Vac
3-Phase
80A
4 w + G
3Φ Wye
100A, 3 Pole
Inverter 1/0
30kVA, 24kW
120/208Vac
3-Phase
4 w + G
3Φ Wye
80A
100A, 3 Pole
1/0
current carrying conductors, (L1,L2,L3,N) @ 40°C
AMPS-2-20
120/208Vac 2-Pole
(or) 120/240Vac Split-
Phase
80A
3 w + G
2Φ
100A, 2 Pole
1/0
20kVA, 16kW
120/208Vac 2-Pole
(or) 120/240Vac Split-
Phase
3 w + G
2Φ
80A
100A, 2 Pole
1/0
AMPS-1-10
120V Single Phase
80A
2 w + G
1Φ
100A, 1 Pole
1/0
10kVA, 8kW
120V Single Phase
2 w + G
1Φ
80A
100A, 1 Pole
1/0
