4.7.4 Bottom Feed Factory Configured Systems (only)
DC -
1
2
3
4
5
6
DC+
Figure 21 — Bottom Feed System, Single Battery Feed
Cable Tie Bar: For use between
all cable landings (6 total)
0260080-J0 Rev D
37
