Front Mount 20 KVA with 19 - 23" Adapter Plates
Front Mount 10 KVA with 19 - 23" Adapter Plates
0260080-J0 Rev D
FRONT MOUNT 20 KVA WITH ADAPTER PLATES
FRONT MOUNT 10 KVA WITH ADAPTER PLATES
19"- 23"
19"- 23"
2X 2 RU ADAPTER PLATE
5901456-002
7X 1/2" TRS SCREWS PER SIDE
5X 1/2" TRS SCREWS
FOR RACK INSTALL
2X 9 RU ADAPTER PLATE
5901456-009
5X 1/2" TRS SCREWS PER SIDE
7X 1/2" TRS SCREWS
FOR RACK INSTALL
PER SIDE
2X 9 RU ADAPTER PLATE
5901456-009
PER SIDE
47
