2. Product Description
The Alpha Modular Power System (AMPS HP2) is a unique, high performance AC and hybrid AC/DC power
system that is ideally suited to provide highly reliable back-up power to cable headend, telecom or server room
facilities.
The AMPS HP2 features hot swappable 2.5 kVA/2.0 kW inverter modules and optional 2.4 kW rectifier modules
that are the building blocks of a highly reliable power system. A smart, unified controller with an integrated Ether-
net/SNMP monitors and manages both inverter and rectifier modules through a web based interface and a local
LCD touch screen. The AMPS HP2 is designed to be installed in a climate-controlled environment where ambient
temperatures are between -20°C to 40°C.

2.1 Power System Configuration Terminology

This section lists the power configurations available with the system and defines the terminology used throughout
this manual.
120Vac Single Phase
A single phase system is 120Vac from L1 to N (neutral).
120/240Vac Split Phase
The term 120/240Vac SPLIT PHASE is used throughout this manual to identify the "3-wire/ 2 legs from a single
phase supply" configuration shown in Figure 1.
120/208Vac 2-Pole
The term 120/208 2-POLE is used throughout this manual to identify the "2-pole from a 3-phase supply" configu-
ration such as L2 to L3 shown in Figure 2
10
Figure 1 — Split Phase from a Single phase supply
L1
240V
N
L2
