3.2 Specifications for 48-2.4kW Rectifier Module

Input Voltage:
Operating:187 to 310Vac
Extended:90 to 187Vac (de-rated power)
Input Frequency:
Power:
Power Factor:
THD:
Efficiency:
Output Voltage:
Output Current:
Load Regulation:
Line Regulation:
Transient Response:
Noise:
Voice Band:<38dBrnC
Wide Band:<20mV RMS (10kHz to 10MHz)
Psophometric Noise:
Acoustic:
MTBF:
Ambient:
Dimensions H x W x D:
Weight:
Temperature:
Operation:-40 to 75°C (-40 to 149°F)
Full Nominal Output Power: -40 to 55°C (-40 to 131°F); >2000W @ 65°C (167°F)
Humidity:
Heat Dissipation:
16
Nominal:208 to 277Vac
44 to 66Hz
2400W continuous
(1200W output @ 120Vac Input)
>0.99 (50 to 100% load)
<5%
96.2% peak
42 to 58Vdc (No load 46.5 to 58Vdc)
44.5A @ 54Vdc (50A max.@ 48Vdc)
(~25A @ 48Vdc at 120Vac Input)
<±0.7% (static)
<±0.1% (static)
±3% for 40 to 90% load step
<150mV peak to peak (10kHz to 100MHz)
<2mV RMS
<60dBa @ 1m (3ft), 30°C
627,000 hours (71 years) per Telcodia SR332 - Issue 3 (2011)
30° C - ground benign, controlled
41mm x 104 mm x 333mm (1.6in x 4.1in x 13.1in)
1.76kg (3.9lb)
Storage:-40 to 85°C (-40 to 185°F)
0 to 95% RH non-condensing
<350 BTU per hour (typical)
<500 BTU per hour (worst case: 100% load at 187 Vac)
Electrical
Mechanical
Environmental
0260080-J0 Rev D
