4.4 Registration Mark Distance Adjustment
The distance between registration marks can be adjusted automatically. If 5 mm was selected for CUSTOM,
for example, and the distance between registration marks was read as 312 mm, any distance less than 5
mm is rounded off to the nearest whole number. In this case, the distance between the registration marks is
assumed to be 310 mm and distance adjustment is performed accordingly.
(1) Press the [PAUSE] key to select PAUSE mode.
(2) Press the [NEXT] key repeatedly until the following menu is displayed.
FORCE
MARK
BUFFER CLR.
SPEED
(3) Press the [F1] key (MARK) to display the registration mark functions selection menu.
FORCE
MODE
TYPE
OTHER SETUPS
SPEED
(4) Press the [F3] key (DIST ADJ) to display the registration mark distance adjustment menu.
FORCE
•USER
SPEED
The currently selected setting is indicated by a black dot [
For manual distance adjustment, press the [F2] key (USER).
For custom distance adjustment, press the [F3] key (CUSTOM).
For automatic distance adjustment, press the [F4] key (STANDARD). The distance adjustment value is rounded up
or down to the nearest 5 mm, 10 mm, or 50 mm according to the registration mark distance setting.
USER
(Manual Input)
(1) Perform registration mark detection. (See Section 4.13, "Registration Mark Detection".
(2) After detection of the number of points set in the registration mark mode has been performed, the menu shown
below is displayed.
FORCE
1-2M
S
SPEED
The display's first line (M) shows the distance between points 1 and 2 as read by the plotter. Input the actual
distance (the data distance) in the second line (S). Use the [
displayed setting is satisfactory, press the [ENTER] key.
If the value you input is exceedingly large (1.5 times or greater) or very small (0.5 times or less), or if the angle of tilt
with respect to the original axis tilt is 45° or greater, the following prompt is displayed. In this case, please re-input
the value.
FORCE
DISTANCE ADJUSTMENT
ERROR. SET AGAIN!
SPEED
OFFSET
TOOL U/D
VIEW
QUALITY
OFFSET
DIST ADJ
QUALITY
OFFSET
CUSTOM
STANDARD
QUALITY
OFFSET
00499.8 mm
00500.0 mm
QUALITY
OFFSET
QUALITY
Chapter 4 REGISTRATION MARK SETTINGS AND DETECTION
•
].
] or [
] key to change the numeric value. When the
4-7
