(6) Press the [F3] key (ADJ. SENS) to display the menu shown below.
FORCE
X ADJUST SENS.
X+
SPEED
(7) Press the [F2] key (X+) to adjust the X-axis sensor, and the [F4] key (Y+) to adjust the Y-axis sensor. The prompt
shown below is displayed.
FORCE
CHANGE TOOL
PRESS ENTER KEY!
SPEED
(8) Mount a plotting pen in tool holder 1.
(9) Press the [CONDITION] key to display a condition settings screen, and then use the [F1] to [F4] keys to select a
COND No. where "PEN" has been selected as the cutter blade type.
(10) Use the [ ] [ ] [
position where you want to plot the cross symbol and then press the [ENTER] key. The plotter plots a cross symbol,
and then the prompt shown below is displayed.
FORCE
CHANGE TOOL
PRESS ENTER KEY!
SPEED
(11) Replace the plotting pen with a cutter pen.
(12) Press the [CONDITION] key to display a condition settings screen, and then use the [F1] to [F4] keys to select a
COND No. where a cutter blade has been selected as the cutter blade type. Press the [ENTER] key. The sensor
reads the plotted cross symbol, and then cuts a second cross symbol. After the second cross symbol has been cut,
the screen shown below is displayed.
FORCE
SENSOR OFFSET ADJUST
X= 0.0 mm
SPEED
Input the difference in values between the first and second crosses. If there is no difference, simply press the [ENTER]
key.
Press the [F2] or [F4] key to move the blinking cursor to X or Y, and then use the [
numeric value. When the displayed setting is satisfactory, press the [ENTER] key to confirm your selection.
Setting range: -9.9 to +9.9 (mm)
Value for Y-axis correction
Y
Cross that was cut after the first cross was read
X
(13) Press the [PAUSE] key to cancel PAUSE mode.
OFFSET
Y
Y+
QUALITY
OFFSET
QUALITY
] [ ] keys to move the pen carriage (the tip of the tool selected by the current setting) to the
OFFSET
QUALITY
OFFSET
Y= 0.0 mm
QUALITY
Cross that was plotted first
Value for X-axis correction
Chapter 4 REGISTRATION MARK SETTINGS AND DETECTION
] or [ ] key to change the
4-13
