5.12 Setting the Distance Adjustment Values

This function is used to correct any discrepancies in the lengths of the cut or plotted line segments. If, for
example, the DISTANCE ADJUST setting is specified as 0.05%, and the distance of the cut is 500 mm, the
cut distance is increased by 500 x 0.05% (= 0.25 mm), which means that the total cut distance is 500.25 mm.
(1) Press the [PAUSE] key to select PAUSE mode.
(2) Press the [NEXT] key repeatedly until the following menu is displayed.
FORCE
I/F
TOOL COND AREA OPT
SPEED
(3) Press the [F3] key (FUNCTION) to display the menu shown below.
FORCE
B.G. SETTINGS
DIST. ADJ
SPEED
(4) Press the [F3] key (DIST ADJ.) to display the distance adjustment values setting screen.
FORCE
DIST.ADJ
X= 0.00%
SPEED
Press the [F2] key to move the blinking cursor to the X= parameter or the [F4] key to move the blinking cursor to the
Y= parameter, and then use the [
Press the [ENTER] key to confirm your selections.
Setting range: -0.25 to +0.25(%), in 0.05(%) increments
(5) Press the [PAUSE] key to cancel PAUSE mode.
These settings are retained in the plotter's internal memory even while the plotter is turned off.
OFFSET
FUNCTION
QUALITY
OFFSET
SORTING
QUALITY
OFFSET
Y= 0.00%
QUALITY
] or [ ] key to change the respective numeric value.
