Chapter 1 PRODUCT SUMMARY
1.1 Model Names and Basic Specifications
The FC2250 series comprises the following models.
Model
FC2250-60VC
FC2250-120MG
FC2250-120ES
FC2250-120VC
FC2250-180ES
FC2250-180VC

1.2 Standard Accessories

Item
Power cable
Cutter pen set
Water based fiber-tip pen
Sheet holder plates
Hexagon wrench
Height adjustment plates
Durable flexible hose
Hose band
Vacuum pump installation base
USB cable
CD-ROM
Quick Start Guide
Usage Precautions
•
The vacuum pump itself is an option. It is not provided with the VC models.
•
Make sure that the vacuum pump used with a VC model is affixed with either a label showing compliance with the
relevant safety standard or with the CE marking.
1-2
Media hold-down method
Vacuum suction
Magnetic
Electrostatic adhesion
Vacuum suction
Electrostatic adhesion
Vacuum suction
Description
PHP31-CB15B-HS, CB15U-2SP, CB15U-K30-5SP
KF552-BK
For MG models only (2 large, 2 medium, 4 small)
For M4 bolts
10 mm, 4 mm height
For VC models only, 1.5 to 5 m (can expand/contract)
Connection bore diameter: φ 38 mm (-60), φ 50 mm (-120/180)
For VC models only, φ 38 mm (-60), φ 50 mm (-120/180)
For VC models only
User's manual, driver, other software
Cutting area
610 x 920 mm
1200 x 920 mm
1740 x 920 mm
Q'ty
1
1 set
1
1 set
1
1 of each
1
2
1
1
1
1
1
