Chapter 1 PRODUCT SUMMARY

1.4 Plotter Nomenclature

The names of the plotter parts are as follows.
Interface connector
USB interface
RS-232C interface
Pen carriage Y bar
USB interface RS-232C interface
1-4
Pen carriage
CHART HOLD key
(ES models only)
Main
box
Power inlet
Power
switch
RS-232C
CHART HOLD key Control panel
Main box Power switch
Y bar
Control panel
Tilt lever
Writing panel Tilt lever
Stand
Writing panel
Stand
Interface connector Power inlet
