A-20
Enhanced I/O Set Interfacing and Application
NPN Sinking Input
Vih = 2.31 V
Vil = 0.99 V
Threshold (nom) = 1.5 V
Iil
= 100 µA
+
12 to
24 V
NPN
NPN Input, Sinking
Figure D.5: NPN Sinking Input on an MDrivePlus 2 Motion Control
Application Example
Sensor using the HOME function.
'[VARIABLES]
S2=1,1,0
Enter to IMS Terminal in Immediate mode or in a Program
HM 1
PNP Sourcing Input
Application Example
Sensor using the Jog+ function.
Vih = 2.31 V
Vil = 0.99 V
Threshold (nom) = 1.5 V
Iih
= -1.24 mA
PNP
12 to
24 V
PNP Input, Sourcing
Figure D.6: PNP Sourcing Input on an MDrivePlus 2 Motion Control
JE=1
S11=7,1,1
MDrivePlus 2
IOPWR
Internal
The internal pull-up voltage
pull-up
cannot provide output
voltage
65 - 160 uA
IOx
100k ohms
Iil
24.9k ohms
IOGND
Sinking Input Equivalent Circuit
'Configure IO2 as a Home Input, active HIGH, sinking.
'Slew at VM - until IO2 = 1, Creep off + at VI
2
MDrivePlus
IOPWR
The internal pull-up voltage
Internal
cannot provide output
pull-up
current / voltage
voltage
IOx
100k ohms
Iih
24.9k ohms
40 - 135 uA
IOGND
'Enable Jog function
'Configure IO11 as a Jog+ Input, active HIGH, sourcing
current / voltage
3.3 V
detect
logic
3.3 V
detect
logic
