All panels can receive power and communication over a single Ethernet cable. Power over
Ethernet (PoE) eliminates the need for a local power supply. PoE requires a PoE injector,
which is sold separately.

Features

•
•
•
•
•
•
•
•
•
TLS 1022T Scheduling Panel — A 10.1-inch (measured diagonally), wall-mounted
panel with a1024x600 capacitive touchscreen.
Dimensions — 7.58" H x 10.51" W x 0.80" D
•
(193 mm H x 267 mm W x 20 mm D)
Mounting — The panel can be mounted outside a conference room by removing
•
the base and using an optional Extron LPVM-1 Low Profile VESA
Mount.
TLS 1025M Scheduling Panel — A 10.1-inch (measured diagonally) wall mounted
panel with a 1280x800 capacitive touchscreen.
Dimensions — 6.84" H x 10.13" W x 1.26" D
•
(174 mm H x 257 mm W x 32 mm D)
Mounting — The panel can be mounted on a non-porous surface, such as a
•
conference room window with the optional Extron SMK 3 Low
Profile Surface Mount Kit. It can be mounted to a wall with the
optional RWM 2 Recessed Wall Mount Kit.
TLP Pro 720M Touchpanel — A 7-inch (measured diagonally), wall-mounted panel
with an 800x480 resistive glass touchscreen.
Dimensions — 6.9" H x 8.7" W x 0.5" D
•
(17.5 cm H x 22.1 cm W x 1.3 cm D)
Mounting — The panel can be mounted in a wall.
•
TLP Pro 720T Touchpanel — A 7-inch (measured diagonally) panel with an 800x480
resistive glass touchscreen.
Dimensions — 6.1" H* x 7.5" W x 7.3" D
•
(15.5 cm H* x 19.0 cm W x 18.6 cm D)
(*Maximum height includes the base, which is discarded for
optional rack mounting.)
Mounting — The panel can be mounted outside a conference room by removing
•
the base and using an optional Extron LPVM-1 Low Profile VESA
Mount.
Make on-demand reservations from the panel, computer, or any smartphone or tablet
that connects to the calendar server.
Make meeting rooms available as soon as a scheduled meeting ends.
Deploy a single panel, or multiple panels with similar settings very easily.
Room Agent software provides easy integration with multiple calendar applications.
No annual subscription or maintenance fees.
Each TouchLink panel model communicates directly with the calendar server.
All communication between the panel and the calendar server is encrypted and secure.
Two bright LED indicators make it easy to see if a room is occupied or available even
from down the hall.
Two color themes, custom loaded background images, and transparency controls
provide personalized branding options.
