Summary of Contents for Extron electronics TouchLink TLP Pro 320M

  • Page 1 User Guide TouchLink ® TLP Pro 320M TouchLink Pro Touchpanel Control Systems 68-2515-01 Rev. B 03 20...
  • Page 2 Safety Instructions Safety Instructions • English Istruzioni di sicurezza • Italiano AVVERTENZA: Il simbolo, , se usato sul prodotto, serve ad This symbol, , when used on the product, is intended to WARNING avvertire l’utente della presenza di tensione non isolata pericolosa alert the user of the presence of uninsulated dangerous voltage within the all’interno del contenitore del prodotto che può...
  • Page 3 Regulatory Compliance Guide』 (P/N 68-290-01) をご覧ください。 Copyright www.extron.com © 2015 - 2020 Extron Electronics. All rights reserved. Trademarks All trademarks mentioned in this guide are the properties of their respective owners. The following registered trademarks ( ® ), registered service marks ( ), and trademarks ( ) are the property of RGB Systems, Inc.
  • Page 4 FCC Class A Notice This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. The Class A limits provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
  • Page 5 Conventions Used in this Guide Notifications In this user guide, the following are used: Potential risk of severe injury or death. WARNING: AVERTISSEMENT : Risque potentiel de blessure grave ou de mort. CAUTION: Risk of minor personal injury. ATTENTION : Risque de blessure mineure.
  • Page 7: Table Of Contents

    Contents Introduction Mounting ............1 ............... 24 About the TLP Pro 320M ........1 Wall or Furniture Mounting ........ 24 Features ............. 1 Other Mounting Options ........26 Application Diagram ........... 2 Underwriters Laboratories Guidelines for Requirements ............. 2 Rack Mounting ..........26 Software ............
  • Page 8 TLP Pro 320M • Contents viii...
  • Page 9: Introduction

    Introduction This guide describes the function, installation, and operation of the TLP Pro 320M TouchLink Pro touchpanel. Unless otherwise stated, the terms “TLP Pro” and “touchpanel” refer to the TLP Pro 320M. This section contains the following information: • About the TLP Pro 320M •...
  • Page 10: Application Diagram

    mounts on a wall, lectern, or any flat surface . Multiple mounting options — Supports Extron Control App and Extron Control for Web. JITC Certified — Successfully completed interoperability and information assurance testing for use in government applications and other mission-critical environments. Application Diagram Motion Sensor LAPTOP...
  • Page 11: Installation Overview

    Installation Overview Before starting, download and install the latest versions of the following software: GUI Designer — for designing layouts for Extron TouchLink Pro touchpanels and … third party touch interfaces. Global Configurator Plus and Professional — for setting up and configuring the …...
  • Page 12 Set up the Touchpanels for Network Communication: Connect the PC that you will use for setup, the control processor, and the touchpanel … to the same Ethernet subnetwork. Use the Setup Menu on page 11 or Toolbelt to set the DHCP status and, if …...
  • Page 13: Panel Features

    Panel Features This section describes: • TLP Pro 320M Front Panel Features • TLP Pro 320M Front Panel Features (Bezel Removed) • TLP Pro 320M Rear Panel Features TLP Pro 320M Front Panel Features C C C D D D A A A B B B B B B...
  • Page 14: Tlp Pro 320M Front Panel Features (Bezel Removed)

    TLP Pro 320M Front Panel Features (Bezel Removed) To release the bezel from the TLP Pro 320M, use the Extron removal tool: Insert the flat edge of the tool into either of the notches in the bottom surface of the bezel figure (see , on page 5).
  • Page 15: Tlp Pro 320M Rear Panel Features

    TLP Pro 320M Rear Panel Features A A A B B B C C C D D D Power connector Reset LED (see page 7) (see page 9) Reset button (see page 8) LAN and PoE Connector (see page 9) Figure 4.
  • Page 16 ATTENTION: • Always use a power supply provided by or specified by Extron. Use of an unauthorized power supply voids all regulatory compliance certification and may cause damage to the supply and the end product. • Utilisez toujours une source d’alimentation fournie ou recommandée par Extron. L’utilisation d’une source d’alimentation non autorisée annule toute conformité...
  • Page 17 Reset LED (see figure 4 on page 7)— is in the center of the rear panel, to the right of the reset button. It indicates power status and reset status of the device (see Reset Modes on page 28). LAN and PoE Connector — is on the right side of the recessed area. Connect the touchpanel to the LAN using a twisted pair cable, terminated with an RJ-45 connector.
  • Page 18 ATTENTION: • The TLP Pro 320M is intended for connection to a Power over Ethernet circuit for intra-building use only and are considered to be part of a Network Environment 0 per IEC TR62101. • Le TLP Pro 320M est conçu pour une connexion à un circuit PoE pour une utilisation intérieure seulement et est considéré...
  • Page 19: Setup Menu

    Setup Menu When the TLP Pro 320M is powered on, the currently loaded project is displayed. To access the setup menu, remove the front panel bezel and press the Menu button (see figure 3 , on page 6). There are five available screens: •...
  • Page 20: Status

    Status Status screen from any other part of the Setup This screen opens by default. To access the Menu icon in the top left corner and then press the Status button. menu, press the Status screen. Because of size of the touchscreen, you The image below shows the entire Status screen at any time.
  • Page 21: Network

    Network Network screen. Because of size of the touchscreen, you The image below shows the entire can only see part of the screen at any time. Flick the touchscreen with your finger to navigate up or down within the screen. Network Revert Apply...
  • Page 22 If DHCP is disabled, set the unit IP address, subnet mask, gateway address, and DNS server address. Press the button for the address to be edited. A screen opens, showing the address and a numerical keypad. IP Address 192.168.254.251 Cancel Figure 11.
  • Page 23: Display

    Display Display screen. You can only see part of the screen at any time. Figure 12 shows the entire Flick the touchscreen with your finger to navigate up or down within the screen. Exit Display Resolution Screen: 320x240 SLEEP TIMER Off, 1 - 120 Minute (s) BRIGHTNESS - 99...
  • Page 24: Audio

    Wake Display — Toggle between On and Off . For this to work, the touchpanel must be • in sleep mode. If Wake on Motion is on, and the touchpanel is in sleep mode, any motion detected by • the motion sensor (see figure ) wakes the panel from sleep mode.
  • Page 25: Advanced

    Advanced Advanced screen. You can only see part of the screen at The image below shows the entire any time. Flick the touchscreen with your finger to navigate up or down within the screen. Exit Advanced PRIMARY CONTROLLER Hostname: IPCP Pro 250 Room1243 IP Address: 192.168.254.250 SYSTEM PROJECT...
  • Page 26: Calibration Screen

    Menu PIN — allows you to enable or disable PIN use. If PIN use is enabled, it allows you to set the PIN or change an existing PIN. By default, PIN use is disabled. on to enable PIN use. The Enter New PIN numeric keypad opens: Set the PIN slider to Enter New PIN Cancel...
  • Page 27: Configuration Software

    Configuration Software This section of the user guide provides information about: • Configuration Software • Downloading Software • TLP Pro 320M Web Page • Updating Firmware Configuration Software These programs provide versatility and adaptability for configuration and control of an AV system as it grows and evolves.
  • Page 28: Downloading Software

    Downloading Software All four programs can be downloaded from www.extron.com. Download tab (see figure 17, Select the Software ( Click Figure 17. Software Downloads from the Extron Website Software Download Center page opens: Figure 18. Software Download Center You may see the product immediately, for example Global Configurator Plus and Professional (see figure 18, ).
  • Page 29: Tlp Pro 320M Web Page

    If the software is not shown in the top panels, you need to search, using the alphabet menu (see figure , on page 20). Click the initial letter of the product. This generates a list of software products withthat initial letter. Scroll through the list until you find the desired product.
  • Page 30: Updating Firmware

    Updating Firmware Firmware for the TLP Pro 320M can be upgraded in one of two ways: • Updating Firmware Using the Touchpanel Web Page on page 23 • Updating Firmware Using Toolbelt on page 23 Before starting, consult your IT team and ensure that the touchpanel has a unique IP address. Downloading Firmware Power on a computer that is connected to the same network as the touchpanel.
  • Page 31: Updating Firmware Using The Touchpanel Web Page

    Updating Firmware Using the Touchpanel Web Page If you have not already done so, download the firmware file to a computer on the same network as the touchpanel (see the previous section). Open the touchpanel Web page (see TLP Pro 320M Web Page (see page 21).
  • Page 32: Mounting

    Mounting This section outlines the various options for: • Wall or Furniture Mounting • Other Mounting Options Wall or Furniture Mounting ATTENTION: • Do not install the TLP Pro 320M in a fire resistant rated wall or partition assembly. • Ne pas installer le TLP Pro 320M dans un mur résistant au feu ou une cloison.
  • Page 33 Setup Menu If required, perform the Initial Calibration using the (see page 11). Press the touchpanel onto the wall plate adapter ( ). Four catches, two on the top and two on the bottom, hold the touchpanel in place. Remove the bezel by inserting the provided Extron pry tool into the notches on the bottom surface of the bezel ( Attach the touchpanel to the wall plate adapter with the two Phillips head screws (#4-40 x ¼...
  • Page 34: Other Mounting Options

    Other Mounting Options Extron provides a range of mounting kits for the TLP Pro 320M. These allow the touchpanel to be mounted on glass surfaces, desktops (fixed or swivel mount), rack mounted (see below for important guidelines about rack mounting), and wall mounted, with a wall box. www.extron.com for the complete range of mounting options.
  • Page 35: Button Kits

    Button Kits Installing or Replacing Buttons The default set of eight front panel buttons are installed on the TLP Pro 320M. Any or all of these buttons can be replaced if they are assigned different functions when the unit is customized.
  • Page 36: Reference Material

    Reference Material This section describes: • Network Port Requirements and Licensed Third-Party Software • Reset Modes • Secure Sockets Layer (SSL) Certificates • IEEE 802.1X Certificates Network Port Requirements and Licensed Third-Party Software For information about network port requirements and licensed third-party software for the touchpanels described in this guide, please refer to the Pro Series Control Product Network Ports and Licenses Guide, which is available at www.extron.com.
  • Page 37: Reset All Ip Settings

    Reset All IP Settings This mode resets all IP settings to factory defaults. Activation To reset all IP settings: Reset button for about 6 seconds until the Power LED blinks twice (once Hold down the at 3 seconds and again at 6 seconds). Reset momentarily (for <1 second) within 1 second.
  • Page 38: Enable Or Disable The Dhcp Client

    Enable or Disable the DHCP Client This mode toggles between DHCP enabled and DHCP disabled. This can also be carried Network screen of out from the Network screen of the Setup menu (see page 13) or the Toolbelt (see the Toolbelt Help File). Activation To enable or disable the DHCP client for the LAN port: Reset button five times (consecutively).
  • Page 39: Ieee 802.1X Certificates

    IEEE 802.1X Certificates IEEE 802.1X is a standard that enables port-based network access control via an authentication server. The protocol requires that all devices must be authenticated before gaining privileges to access the secure part of the network. The Extron implementation of 802.1X supports PEAP - MSCHAPV2 and EAP - TLS methods of authentication.
  • Page 40 Extron Electronics makes no further warranties either expressed or implied with respect to the product and its quality, performance, merchantability, or fitness for any particular use. In no event will Extron Electronics be liable for direct, indirect, or consequential damages resulting from any defect in this product even if Extron Electronics has been advised of such damage.
