Features

•
•
•
•
•
•
•
•
•
•
•
•
•
LCD touchscreen
TLP Pro 525C — 5" capacitive flip-up touchscreen with 800x480 (WVGA) resolution
•
TLP Pro 725C — 7" capacitive flip-up touchscreen with 1024x600 (WSVGA) resolution
•
24-bit color depth. Vibrant edge-to-edge glass display with a more responsive control
•
surface.
Gorilla Glass screen is tough, scratch, and smudge-resistant — Corning
®
Glass is stronger and more scratch-resistant than standard glass, while maintaining touch
sensitivity, color saturation, and brightness.
Faster, quad-core processing — provides enhanced response and overall user
experience.
Power over Ethernet (PoE 802.3af, class 3) compliance — provides power and
communication over a single Ethernet cable
Compatible with the full range of Extron IPL Pro and IPCP Pro control processors
— allows easy integration into existing systems.
Built-in speaker — provides audible feedback from button presses.
Patented modular design for fast assembly and serviceability — AV connectivity can
be installed or serviced from the top of the enclosure after the enclosure is installed.
Series/2 Cable Access Enclosure design offers easy access to AV, data, and power
connections:
The TLP Pro 525C enclosure accommodates:
Series/2 AC or AC+USB power module and either five AV cables, or two single space
•
MAAPs, or two Retractors.
AC Power and AC+USB Power Modules are available for US, Europe, and other major
•
world markets.
Optional Retractor cable retraction system supports most AV, data, and power.
•
Included TLP Pro 525C Bracket Kit provides additional flexibility when configuring the
•
Cable Cubby.
The TLP Pro 725C enclosure accommodates up to three Series/2 modules in a variety of
configurations. There are three different types of modules:
Accommodates Series/2 AC or AC+USB power module, plus three Retractors, eight AV
•
cables, and/or three AAP – Architectural Adapter Plates per bracket.
AC Power and AC+USB Power Modules are available for US, Europe, and other major
•
world markets.
Optional Retractor cable retraction system supports most AV, data, and power.
•
Included Cable Cubby Series/2 Connectivity Bracket Kits provide additional flexibility
•
when configuring Cable Cubby Series/2 cable access enclosures.
Compatible with TeamWork Show Me Cables — Show Me cables provide convenient
connectivity and user input selection and control for TeamWork Collaboration Systems. Visit
the TeamWork System Builder at
collaboration environment.
Integrated side clamps secure enclosure to the furniture surface — the Cable Cubby
can be secured in place without additional parts or tools.
System connection status indicator — the communication LED provides visual feedback
if the touchpanel is not communicating with a control processor.
Automatic clock synchronization — allows the touchpanel to display the accurate time
and date.
Energy-saving features —
Light sensor adjusts screen brightness as the ambient room lighting changes.
•
Adjustable sleep timer puts the touchpanel into sleep mode.
•
TLP Pro 525C and 725C Series Touchpanels • Introduction
(power injector sold separately).
