Chapter 3: Jumpers and Connectors
M.2 2230 E-Key Connector (PCIe3.0 x2 + USB2.0 interface) for Wi-Fi Module or Hailo AI Card
Connector location: CN15
75
74
1
2
Pin
Definition
1
GND
3
M2_USB_DP
5
M2_USB_DN
7
GND
9
N.C
11
N.C
13
N.C
15
N.C
17
N.C
19
N.C
21
N.C
23
N.C
25
KEY(Notch location)
27
KEY(Notch location)
29
KEY(Notch location)
31
KEY(Notch location)
33
GND
35
M2_PCIE0_TXP
37
M2_PCIE0_TXN
39
GND
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
2
VDD_3V3
4
VDD_3V3
6
WLAN_LED#
8
N.C
10
N.C
12
N.C
14
N.C
16
N.C
18
GND
20
N.C
22
N.C
24
KEY(Notch location)
26
KEY(Notch location)
28
KEY(Notch location)
30
KEY(Notch location)
32
N.C
34
N.C
36
N.C
38
N.C
40
N.C
Pin
Definition
41
M2_PCIE0_RXP
43
M2_PCIE0_RXN
45
GND
47
M2_PCIE0_CLKP
49
M2_PCIE0_CLKN
51
GND
53
M2_PCIE_CLKREQ0
55
M2_PCIE0_WAKE#
57
GND
59
M2_PCIE1_TXP
61
M2_PCIE1_TXN
63
GND
65
M2_PCIE1_RXP
67
M2_PCIE1_RXN
69
GND
71
M2_PCIE1_CLKP
73
M2_PCIE1_CLKN
75
GND
33
Pin
Definition
42
N.C
44
N.C
46
N.C
48
N.C
50
M2_32.768K
52
PCIE_RESET0#
54
BT_DISABLE#
56
WIFI_DISABLE#
58
M2_I2C_SDA
60
M2_I2C_SCL
62
N.C
64
N.C
66
PCIE_RESET1#
68
M2_PCIE_CLKREQ1
70
N.C
72
VDD_3V3
74
VDD_3V3
VTC 7260 Series User Manual
