Teldat S.A.
DIN rail mount: Position 1
Fig. 11:
DIN rail mount: Position 2
Fig. 12:
3.4 Wall mounting
The Regesta Smart PLC can be mounted on a wall thanks to three holes. To ensure it is properly fastened, screws
must be inserted in said holes. Before mounting the device on the wall, remove the protective case.
The following image shows where the fastening holes are located:
Regesta Smart PLC
3 Installing the Router
15
