3 Installing the Router
To replace the protective case, follow the steps below.
First, place the case in the correct position by sliding it downwards onto the device:
Lock the case in place by turning the fastening mechanism a quarter turn to the horizontal position and pushing
down. You should hear a little click.
Warning
The protective case must be replaced before you apply power to the device.

3.3 Installing a DIN rail mount accessory

The Regesta Smart PLC can be installed on a standard DIN rail. A special kit is required to mount the device on the
DIN rail. This kit is included with delivery of the device. The DIN rail kit allows the device to be installed in different
positions.
The kit contains 2 screws for fixing the rail mount to the device. The holes on the bottom of the device allow you to
place the DIN rail mount in two different positions:
