A.2.4 WAN Base-T Interface
STANDARDS
PORTS
SPEED
CONNECTOR
ISOLATION
A.2.5 WAN SFP Interface
STANDARDS
SPEED
TYPES
CONNECTOR
A.2.6 Wireless WAN interface
WWAN Standard/Bands
Speed (DL/UL)
CONNECTOR
SIM Slots
Regesta Smart PLC
Ethernet (802.3).
1 port with MDI/MDX auto detection.
10/100/1000 Mbps (Base-T).
RJ-45 female.
High isolation for E2 (up to 10 KV).
802.1Q (VLAN).
1000-Base-X.
MSA and SFF 8472 compliant.
1000 Mbps full duplex.
LX/LH (single-mode 1310 nm).
SX (multi-mode 850 nm).
ZX (single-mode 1550 nm).
Standard SFP connector.
EC25-E:
• LTE:
• FDD. B1, B3, B5, B7, B8, B20
• TDD: B38, B40, B41
• WCDMA: B1, B5, B8
• GSM/GPRS/EDGE: 900/1800 MHz
EC25-E:
• LTE Cat 4.
• FDD. 150Mbps/50Mbps
• TDD: 130Mbps/35Mbps
• HSPA+ Cat 24/6: 42Mbps/5.76Mbps
• EDGE: 236Kbps
Two RF SMA female connectors. (Optional).
2 Mini-SIM (2FF) ISO/IEC 7810:2003, ID-000 (1.8V / 3V)
