A.1.7 RS-485 Serial Port Connectors
RJ45
A.1.8 Power Supply Connector
2 wire 5.08 mm pitch terminal
block
A.2 Technical Specifications
A.2.1 Hardware Architecture
MEMORY
STORAGE UNIT
A.2.2 PRIME PLC Interface
PROTOCOL
ROLE
COMMUNICATIONS
TECHNOLOGY
CONNECTOR
A.2.3 LAN Interface
PROTOCOLS
PORTS
SPEED
CONNECTOR
ISOLATION
34
PIN
2
3
6
7
Phase and Neutral connectors without assignation
128 Mbytes in SDRAM.
FLASH Memory (32 Mbytes).
PRIME 1.3.6 and PRIME 1.4 depending on the firmware uploaded.
Base Node
Single phase injection:
PRIME 1.3 CENELEC A band.
PRIME 1.4 Multiband (CENELEC, FCC and ARIB) bands
MicroChip ATPL360 chipset.
Terminal Block 2 Poles 5.08 mm pitch, is the same as power supply.
Ethernet (802.3).
1 port with MDI/MDX auto detection.
10/100/100 Mbps (BaseT).
RJ-45 female.
Standard for E1 interface (1.5 KV).
SERIAL
2H_R/TX-_4H_TX-
2H_R/TX+_4H_TX+
4H_RX+
4H_RX-
Teldat S.A.
Regesta Smart PLC
