Chapter 4 Connecting the router
This chapter describes how to connect the Regesta Smart PLC router to Ethernet devices and networks. The chapter
contains the following sections:

4.1 Power Source

Note
Please read the following instructions carefully before connecting the router!

4.1.1 Power Connector pins

The power connector is located on the connector panel.
Power Supply Connector
Fig. 14:
The power connector on this router is a 5.08 mm pitch 2-wire terminal block.
There is no assignation for Phase and Neutral signals.
