3 Components and Power Supply
Front Panel, side view
Fig. 5:
3.2.2 Wall mounting
The Teldat Connect-4GePlus can be mounted on the wall.
There are two slots on the underside of the device, used to fix it to the wall. You can see this in
page 8.
We recommend the following accessories for wall mounting, valid for solid and Gypsum board (plaster) walls:
• 2 screws: [3.5x30 coach screw with a 90-degree head angle].
Screw
Fig. 6:
• 2 wall anchors: [8mm diameter white ribbed wall anchor].
Wall anchor
Fig. 7:
Warning
The screws must go into a wall stud (wood) or a wall anchor of the appropriate type for the wall. Screws
into drywall are not strong enough to mount the device.
There are two slots on the underside of the device that can be used to fix it to the wall. You can see this in the follow-
ing figure:
10
Teldat S.A.
Underside Panel
on
Teldat Connect-4GePlus
