3 Components and Power Supply
Security Slot
Fig. 7:

3.3 Installation

3.3.1 Standalone

Teldat Connect-FW devices can be placed as standalone on a flat, stable surface.
Make sure there is enough space around the router (for ventilation purposes) and check that the power cord and
data cables can easily reach it.
Workplace conditions. Main characteristics:
• Avoid humid and/or dusty locations.
• Direct exposure to sunlight and other heat sources should be avoided. The device should not be placed amongst
papers, magazines or other elements that could hinder natural air circulation.
• The device should not be placed close to strong electromagnetic fields (such as speakers, engines, etc.).
• Knocks and/or strong vibrations should be avoided during transport, operation and storage.

3.3.2 Wall mounting

The Teldat Connect-FW can be mounted on the wall.
There are two slots on the underside of the device that allow it to be fixed to the wall.
We recommend the following accessories for wall mounting, valid for solid and Gypsum board (plaster) walls:
• 2 screws: [3.5x30 mm coach screw with a 90-degree head angle].
Screw
Fig. 8:
• 2 wall anchors: [8 mm diameter white ribbed wall anchor].
Wall anchor
Fig. 9:
Warning
The screws must go into a wall stud (wood) or a wall anchor of the appropriate type for the wall. Screws
into drywall are not strong enough to mount the router.
