2 Product Overview
D
E
F
G
H
10
- WAN SFP Connector on page 32
- WAN SFP Interface on page 35
WAN Gigabit Ethernet. RJ-45 connector.
For more information about the WAN interface with Base-T connector, refer to:
- WAN connections on page 19
- WAN Base-T Connector on page 32
- WAN Base-T Interface on page 35
LAN Gigabit Ethernet Port.
For more information about the LAN interface, refer to:
- LAN connection on page 18
- LAN Connector on page 32
- LAN Interface on page 34
POWER/PLC. Power connection and PLC signal injection.
For more information about the power connection options, refer to:
- Power Source on page 17.
- Power Supply Specifications
For more information about the PLC connection options, refer to:
- PLC connection on page 20.
- PRIME PLC Interface on page 34.
DCE RS-232 serial ports or RS-485 2-4 wires/RS-422.
The type of configuration of each port depending on the hardware configuration of the
device (model).
For more information on the connector for serial ports, 2-4 wire RS-485/RS-422 and RS-232
DCE, refer to:
RS232 option:
- RS-232 Serial Port on page 23
- RS-232 Serial Port Connectors
- RS-232 Serial Interface on page 36
RS485 option
- RS-485/RS-422 Serial Port
- RS-485 Serial Port Connectors
- RS-485 Serial Interface on page 36
RF/WWAN antenna connectors for the Cellular interface, depending on the model.
For more information about the Cellular interface, refer to:
- WWAN Antenna connections (RF connectors)
on page 36
on page 33
on page 23
on page 34
on page 20
