3.2 Installation

In the following sections you can find guidelines for the Atlas-840 installation.
Warning
Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Warning
This unit is intended for installation in restricted access areas.
A restricted access area can be accessed by skilled, instructed, or qualified personnel.

3.2.1 Standalone

Atlas-840 devices can be placed as standalone devices on a flat, stable surface. The adhesive rubber feet must be
stuck to the underside panel to prevent the router from sliding.
Make sure there is enough space around the router (for ventilation purposes) and check that the power cord and
data cables can easily reach it.
Workplace conditions. Main characteristics :
• Avoid humid and/or dusty locations.
• Direct exposure to sunlight and other heat sources should be avoided. The device should not be placed amongst
papers, magazines or other elements that could hinder natural air circulation.
• The device should not be placed close to strong electromagnetic fields (such as speakers, engines, etc.).
• Knocks and/or strong vibrations should be avoided during transport, operation and storage.

3.2.2 Wall mounting

Atlas-840 devices cannot be mounted on the wall.

3.2.3 19'' Rack installation

Atlas-840 devices can be installed in a 19" rack.
The Rack Mounting Kit consists of two brackets, eight screws and six rack screws with cage nuts.
To install the kit, follow these steps:
• Step 1. Attach the brackets to the router using the screws provided. Use a Phillips PH1 screwdriver to fasten the
screws.
Teldat Edge Router Atlas-840
Refer to Ground the router on page 9 for more information.
Power socket.
Refer to Power source on page 9 for more information on Power Connection and
Power supply on page 20 for power specifications applicable to the Atlas-840
device.
